성민전기
AC Spark Tester
모델명
시리즈
Cable Instruments
구매 안내
아래는 참고용 정보이므로 세부 조건은 반드시 제조사/판매자에게 문의 바랍니다.
결제 방법
제조사/판매자에게 문의 바랍니다.
납기 정보
제조사/판매자에게 문의 바랍니다.
배송 정보
제조사/판매자에게 문의 바랍니다.
원산지
제조사/판매자에게 문의 바랍니다.
제품 상세 설명
Installed in a cable manufacturing line, an AC SPARK TESTER is a general tester that has been used for several decades to detect bad insulation. It is a very general tester used to find the location of sparks resulting from the wire’s spiral, pinhole, dents, and alien substances.
Depending on the exterior appearance, it can be classified into three types.
1) Control separation type - The Detector and the Control Unit are separately installed.
You can install the Control Unit in the controller or near the workers for use.
2) Integrated compact type - The Detector and the Control Unit are integrated as one unit.
Great exterior appearance and compact size. Can support safe use of up to 30,000V.
3) Extra-large integration type - Extra-large size. Supports safe use in the ultra-high voltage cable of up to 40,000V.
Product Specs
| Model Name | Product Size | Applicable Cable Diameter | Test Voltage | Electrode Length |
| SM-15ST40 | 500X300X1170 | 20mm | 15KV 50/60Hz | 350mm |
| SM-15ST80 | 600X480X1250 | 40mm | 15KV 50/60Hz | 250mm |
| SM-15S120 | 600X480X1250 | 80mm | 15KV 50/60Hz | 250mm |
| SM-15ST180 | 800X600X1250 | 150mm | 15KV 50/60Hz | 250mm |
| SM-30ST80 | 600X480X1250 | 40mm | 30KV 50/60Hz | 250mm |
| SM-30ST120 | 600X480X1250 | 80mm | 30KV 50/60Hz | 240mm |
| SM-30ST180 | 800X650X1350 | 150mm | 30KV 50/60Hz | 240mm |
| SM-40ST120 | 800X650X1350 | 80mm | 50KV 50/60Hz | 220mm |
| SM-40ST-180 | 800X650X1350 | 150mm | 50KV 50/60Hz | 220mm |
| SM-40ST-300 | 800X800X600 | 150mm | 50KV 50/60Hz | 300mm |
| SM-15ST-20 | 300X170X250 | 10mm | 15KV 50/60Hz | 80mm |
