CHARACTERISTICS

• Continuous duty S1.
• 2 pole motor.
• Insulation class F.
• Protection IP42
• Working tolerance: ±10%.
• Limit ambient temperature : +40 °C.
• Normal priming, manometer suction up to 5m.
• For clear waters/oils and medium dilutions, without abrasive substances.

ON REQUEST

• Special voltages.
• Dual-frequency.
• Other IP degrees
• cRUus certified motors for selected tensions

VERSIONS

• ST Water -20/+140℃, Oil -20/+180℃
• WT Water -20/+200℃
• HT Diatermic Oil -20/+350℃
• CT Cryogenic Application -100/+120℃

MATERIALS

• Body AISI316
• Rotor AISI316/PEEK
• Crank shaft AISI316
• Pump shaft CERAMICA
• Bushings SiC

WEIGHT
4.1 ㎏

IN ACCORDANCE WITH

• EN 60034-1
• EN 60034-30
• EN 60335-1
• EN 60335-2-41

DIMENSIONS

HYDRAULIC PERFORMANCE
