제품 상세 정보
STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| YOKE | ductile, cast steel or alductile, cast steel or al |
| PISTON & CYLINDER | stainless steel or carbon steel |
| STEM | 304SS |
| SPRING SEATS | 304SS |
| LONG BOLTS | carbon steel |
| SPRING | oil tempered wire, carbon steel, or alloy steel |
SPECIFICATIONS
1) Pistone Size: Ø150mm, Ø200mm,
Ø250mm, Ø300mm,
Ø350mm, Ø420mm,
Ø450mm, Ø500mm,
Ø550mm, Ø600mm,
Ø650mm
2) Operating Spring Range: 1.0 ~ 2.0 bar, 2.0 ~ 3.0 bar, 2.5 ~ 3 bar
3) Supply Pressure: Air4 ~ 7 kgf/cm2g
4) Control Characteristics: Throtting, On-off
5) Signal Connection: (N)PT Screwed
6)Ambient Temperature: -25 ~ 80℃
7)Color: Blue, etc.
