STANDARD MATERIALS

NOTE

1) All the Stainless Steel Available
    ASTM A105, ASTM A182-F11 / F22 / F91
    ASTM 182 F304 / F316
2) 316SS + Stellite Welding(#6) or 410SS + Q.T

SPECIFICATIONS

1) Valve Size : 1" ~ 12"
2) Applicable Rating : ASME 150# ~ 450#
3) Temperature : Up to 600℃
4) Code & Standard : API, BS, ASME, ASTM, KGSC
     Designed by ASME B16.10 / 16.25 / 16.34 / 16.5,
     API 598 & ISA Standard
5) Allowable Seat Leakage : IV, V, VI, Zero
6)Control Characteristics
    EQ% , Linear , Modified , Q-Opening
7)Additional Equipments
    Pneumatic & MOV Actuator
    Positioner , Air set , Solenoid V/V ETC.
