STANDARD MATERIALS

NOTE

1) ASTM A351-CF8(M), CF3(M)

SPECIFICATIONS

1) Valve Size : 1/2" ~ 36"
2) Applicable Rating : ASME 150# ~ 2500#
3) Temperature : Down to -196℃
4) Code & Standard : BS, ASME, ASTM, KGSC
     Designed by BS6364, ASME B16.34, and ASME B16.11/16.5
5) Constructions
   - End Connection : Butt-Welded or Flanged Type
   - Extended Bonnet
   - Trunnion Ball, Full Bore / Reduce Bore
   - Fire Safety Construction (Certified by TÜV)
   - Manual or Motor Operated
     (Pneumatic, Electric, or Hydraulic)
   - Uni- / Bi-Direction, Double Block & Bleed Design
6) Feature : Patent 10-0835853 (Korea)
     NEP Certification (No. NEP-MKE-2009-026)
