제품 상세 정보
STANDARD MATERIALS
| PART NAMES | MATERIALS |
|---|---|
| BODY | NOTE 1) |
| BONNET | NOTE 1) |
| SEAT | SOFT : PCTFE, METAL : ASTM A276-304(L)/ 316(L)-(H.F) |
| DISC | ASTM A351-CF8(M) / CF3(M), A276-304(L) / 316(L)-(H.F) |
| GASKET | SPIRAL WOUNDED GRAPHITE |
| ARM | ASTM A351-CF8(M) / CF3(M) |
NOTE
1) Cast Steel, ASTM A351-CF3(M) / CF8(M)
SPECIFICATIONS
1) Valve Size : 2" ~ 36"
2) Applicable Rating : ASME 150# ~ 600#
3) Temperature : Down to -196℃
4) Code & Standard : BS, ASME, ASTM, KGSC
Designed by BS6364, ASME B16.34, and ASME B16.11/16.5
5) Shell & Seat Leak Test : ASME B16.34
6) Constructions
- End Connection : Flanged, Butt-Welded or RTJ Type
- Full Bore
