STANDARD MATERIALS

NOTE

1) All the Stainless Steel Available
     ASTM A216-WCB, ASTM A217-WC6 / WC9 / C12A
     ASTM 352-LCB / LC1 / LC2 / LC3
2) 316SS + Stellite Welding(#6) or 410SS + Q.T

SPECIFICATIONS

1) Valve Size : 1" ~ 24"
2) Applicable Rating : ASME 150# ~ 4500#
3) Temperature : Up to 600℃
4) Code & Standard : API, BS, ASME, ASTM, KGSC
     Designed by ASME B16.10 / 16.25 / 16.34 / 16.5,
     API 598 & ISA Standard
5) Allowable Seat Leakage : IV, V, VI, Zero
6)Control Characteristics
    EQ% , Linear , Modified , Q-Opening
7)Additional Equipments
    Pneumatic & MOV Actuator
    Positioner , Air set , Solenoid V/V ETC.
