STANDARD MATERIALS

note
1. All the Stainless Steel Available
2. HIGH TEMP. : ASTM A216-WCB, ASTM A217-WC1 / WC6 / WC9,
     LOW TEMP. : ASTM A352-LCB / LC1 / LC2 / LC3

SPECIFICATIONS

1) Valve Size : 2" ~ 36"
2) Applicable Rating : ASME 150# ~ 600#
3) Temperature : Up to 500℃
4) Code & Standard : API, BS, ASME, ASTM, KGSC
     Designed by ASME B16.10 / 16.25 / 16.34 / 16.5,
     API 598 / 600 and BS1414
5) Constructions
    - End Connection : Butt-Welded or Flanged Type
    - BB (=Bolted Bonnet) Type
    - Full Bore
    - Manual or Motor Operated
      (Pneumatic, Electric, or Hydraulic)
