| Process Fluid: |
Display: |
| Liquid, Gas of Vapor |
9-digit totalizer, 6-digit flow rate |
| Application: |
Display Unit: |
| Differential pressure flow measurement |
32 flow engineering unit |
| Pressure Range: |
5 Digits programmable for special unit |
| 0 - 2500kPa |
Keypad: |
| Flow Range: |
3 internal keys for programming |
| 0 - 999999 |
and output setting |
| Turndown Ratio: |
Current Output: |
| 20 : 1 |
4 - 20 mA 2 wires |
| Accuracy: |
with Hart signal (Compatible) |
| +/- 0.075% of span |
Load |
| Stability: |
Rohm=(Vdc-9)*50 |
| +/-0.15% of URL for 2 years |
Pulse Output: |
| Working Temperature: |
Scale Pulse |
| -25 to +95 oC |
Power Supply: |
| Max. Pressure: |
9 - 36 VDC |
| 40 Mpa |
Damping: |
| Material: |
0 - 32 seconds |
| Flange/Adapter |
Humidity Limit: |
| Stainless Steel 304 / Stainless Steel 316 |
0 to 100% Relative Humidity |
| Drains/Vents |
Turn on Time: |
| Stainless Steel 304 / Stainless Steel 316 |
2 Seconds with minimum damping |
| Diaphragm |
Zero Calibration: |
| Stainless Steel 316L / Hastelloy B / |
Automatic zero calibration by press-button |
| Hastelloy C / Monel / Tantalum |
Cable Entry: |
| Wetted O-Ring |
M20 Conduit Threads / 1/2" NPT (Female ) |
| Buna N / Viton / PTFE |
Temperature Effect: |
| Bolts & Nuts |
+/-0.18% of span per 20 oC |
| Carbon Steel / Stainless Steel 316 |
Vibration Effect: |
| Mounting Bracket |
+/-0.05% of URL per g to 200 Hz in any |
| Carbon steel / Stainless Steel 304 / 316 |
axis |
| Name / Tag Plate |
EMI/RFI Effect: |
| Stainless Steel 304 / Stainless Steel 316 |
Follow SAMA PMC 33.1 from 20 to 1000 |
| Converter Housing |
MHz and for field strengths up to 30 V/m |
| Low copper cast aluminum alloy with |
Process Connection: |
| polyurethane, light blue paint |
1/4 - 18 NPT |
| Fill Fluid: |
1/2 - 14 NPT (with adapter) |
| Silicone / Fluorine Oil |
Ambient Temperature: |
| Protection Class: |
-25 to +80 oC |
| IP67 (Standard ) |
Dimensions: |
| Intrinsically Safe EEx ia IIC T5 (Standard) |
102 mm (W) * 188 mm (H) * 130 mm (D) |
| Explosion proof Ex D IIB T5 (Optional) |
Weight: |
| Mounting: |
3.5 Kg |
| Direct Mounting / Bracket on 2" Pipe |
