Specification

Form factor

Dimensions 1U Rack Optimized, 322x44x183mm(W x H x D)

Platform

Processor OCTEON Plus CN50xx Single/Dual Core MIPS64 Based Embedded Processor

System Memory

Memory Type DDR2 667MHz SO-DIMM 32bit
Memory Capacity Up to 2GB DDR2 Memory

Network interface

2x Copper GbE(RTL8212)
4x Copper Switch(RTL8366)

Storage

Storage Interface 1x 2.5' SATA II HDD
CF 1x Compact Flash

Peripheral

USB 1x USB 2.0 Port
Serial 1x Console Port(RJ45 Type)

Expansion & Option Card

1x Mini PCI

Display

LEDs Power LED, HDD LED, Bypass LED

Power

Watt SMPS 12V adapter
Input 100V~240V AC 50~60MHz auto range

Environmental Parameters

Temperature Operating 0~40℃, Storage -20~75℃
Humidity(RH) Operatiog 5~85%, Storage 5~95%
