Specification

Form factor

Dimensions 1U Rackmount, 428x44x405mm(W x H x D)

Platform

Processor OCTEON Plus CN52xx Multi Core MIPS64 Based Soc Processor

System Memory

Memory Type DDR2 667/800MHz DIMM
Memory Capacity Up to 8GB DDR2 Memory

Network interface

4x Copper/Fiber Combo GbE, w/1-Pair LAN Bypass
2x Copper 10/100Mbps Ethernet

Storage

Storage Interface 1x SATA II HDD
CF 1x Compact Flash

Peripheral

USB 2x USB 2.0 Port
Serial 1x Console Port(RJ45 Type)1x AUX(RJ45 Type)

Expansion & Option Card

1x Mini PCIe

Display

LEDs Power LED, HDD LED, Status LED
Module LCD(2x16 Character, BLUE)

Power

Watt 150W Single ATX PowerRedundant Power System Available(2U)
Input 100~240V AC 47~63MHz auto range

Environmental Parameters

Temperature Operating 0~40℃, Storage -20~75℃
Humidity(RH) Operatiog 5~85%, Storage 5~95%
