Specification

Form factor

Dimensions 1U Rackmount, 428x44x405mm(W x H x D)
Weight 7Kg

Platform

Processor OCTEON II CN61xx Multi Core MIPS64 Processor

System Memory

Memory Type DDR3 800/1066/1333MHz DIMM
Memory Capacity Up to 8GB DDR3 Memory

Network interface

8x Copper GbE, w/1-Pair LAN Bypass
2x Copper GbE

Storage

Storage Interface 1x SATA II HDD
CF 1x Compact Flash

Peripheral

USB 2x USB 2.0 Port
Serial 1x Console Port(RJ45 Type)

Display

LEDs Power LED, HDD LED, Status LED

Power

Watt 150W Single ATX Power
Input 100~240V AC 47~63MHz auto range

Environmental Parameters

Temperature Operating 0~40℃, Storage -20~75℃
Humidity(RH) Operatiog 5~85%, Storage 5~95%
