• Support Dual Processor(Jasper)
• 6 DIMMs DDR3
• 2 Copper GbE
• Up to 32 LAN ports via 4 network modules
• Modular design for easy replacement and maintenance



 Specification

Form factor

Dimensions 2U Rackmount, 440x88x550mm(W x H x D)
Weight 13Kg

Platform

Processor Intel Jasper Processor
Chipset Intel IBEX PEAK 3420

System Memory

Memory Type DDR3 800/1066/1333MHz Registered/Unbuffered DIMM
Memory Capacity Up to 48GB DDR3 Memory

Network interface

2x Copper GbE(Intel82574L)

Storage

Storage Interface 2x SATA II HDD
CF 1x Compact Flash

Peripheral

USB 2x USB 2.0 Port
Serial 1x Console Port(RJ45 Type)
VGA 1x Internal VGA port

Expansion & Option Card

 4x Fiber GbE, w/LAN Bypass or w/o LAN Bypass
 8x FIber GbE
 4x Copper GbE w/LAN Bypass
 8x Copper GbE
 2x Fiber 10 GbE w/LAN Bypass or w/o LAN Bypass

Display

LEDs Power LED, HDD LED, Status LED
Module LCD(2x16 Character, BLUE)

Power

Watt 601W Redundant ATX Power
Input 103V~240V AC 50~60MHz auto range

Environmental Parameters

Temperature Operating 0~40℃, Storage -20~75℃
Humidity(RH) Operatiog 5~85%, Storage 5~95%
