Intel® Celeron Braswell N3150 1.6GHz 4cores
 up to 8GB
 1 x DDR3L 1600MHz SODIMM
 4x Copper Gbe (Intel i210), w/ 1 pair bypass (option)
 2 x SATA3 ports (1x SATADOM support)
 Power LED , HDD LED, Status LED
 12V 40W Open frame Power
 1x CPU FAN, 1x System FAN



 Specification

Form factor

Dimensions 1U Rackmount

Platform

Processor Intel® Celeron N3150 1.6GHz 4cores

System Memory

Memory Type 1 x DDR3L 1600MHz SODIMM
Memory Capacity up to 8GB

Network interface

4x Copper Gbe (Intel i210), w/ 1 pair bypass (option)

Storage

Storage Interface 2 x SATA3 ports (1x SATADOM support)
ETC 1 x Internal eMMC

Peripheral

USB 2 x USB 3.0 ports
Serial 1 x Console port (RJ45)
VGA 1 x HDMI port, 1 x VGA port (Option)

Display

LEDs Power LED , HDD LED, Status LED

Power

Watt 12V 40W Open frame Power

Environmental Parameters

Temperature Operating 0~40℃, Storage -20~75℃
Humidity(RH) Operatiog 5~85%, Storage 5~95%
