STANDARD SPECIFICATION

- Capacity : Max. 800 m³/hr
- Total Head : Max. 100 mH
- Temperature : Max. 150℃
- Impeller Type : Open (special : revers-vane)
- Bore : 25A ~200A
- Rotation : CW (View from drive end)

FEATURES

- Full compliance with ANSI B73.1M standard
- Self-priming pump driving automatically
- High efficiency over a wide range
- Heavy Duty Design
- Low NPSHr with Open impeller
- Easy assembly with BACK PULL-OUT structure
