STANDARD SPECIFICATION

- Capacity : Max. 600 m³/hr
- Total Head : Max. 60 mH
- Temperature : Max. 110℃
- Impeller Type : Semi-Open
- Bore : 25A ~250A
- Rotation : CW (View from drive end)
- Sealing system : Mechanical Seal
                                 Single seal
                                 Double seal

FEATURES

- High corrosion resistance
- Complete standardization with precise forming of all parts
- High efficiency over a wide range
- Low NPSHre with Open impeller
- Easy assembly with BACK PULL-OUT structure
