Features

- Face to face : Maker standard
- End flange : ASME B16.5 , JIS B2238
- Shell wall thickness : ASME B16.34 & BS5351
- Anti-static device
- Locking device
- Blow-out proof stem

Specifications

- Size : T/T-Port & T/L-Port DN15 (1/2") ~ DN350 (14")
- Y-Type (Divert) DN65 (2-1/2") ~ DN400 (16")
- Pressure Rating : Class 150, JIS 10K
- Working Temperature : '-29°C ~ +180°C
