| Nominal Pipe Size (NPS) | Outside Diameter | Center-to-End |
| A | B | D1 | D2 | C | M |
15×15×15
20×20×20
20×20×15 | ½×½×½
¾×¾×¾
¾×¾×½ | 21.7
27.2
27.2 | 21.7
27.2
21.7 | 25.4
28.6
28.6 | 25.4
28.6
28.6 |
25×25×25
25×25×20
5×25×15 | 1×1×1
1×1×¾
1×1×½ | 34.0
34.0
34.0
| 34.0
27.2
21.7 | 38.1
38.1
38.1 | 38.1
38.1
38.1 |
32×32×32
32×32×25
32×32×20
32×32×15 | 1¼×1¼×1¼
1¼×1¼×1
1¼×1¼×¾
1¼×1¼×½ | 42.7
42.7
42.7
42.7
| 42.7
34.0
27.2
21.7 | 47.6
47.6
47.6
47.6
| 47.6
47.6
47.6
47.6
|
40×40×40
40×40×32
40×40×25
40×40×20
40×40×15
| 1½×1½×1½
1½×1½×1¼
1½×1½×1
1½×1½×¾
1½×1½×½
| 48.6
48.6
48.6
48.6
48.6
| 48.6
42.7
34.0
27.2
21.7 | 57.2
57.2
57.2
57.2
57.2 | 57.2
57.2
57.2
57.2
57.2 |
50×50×50
50×50×40
50×50×32
50×50×25
50×50×20 | 2×2×2
2×2×1½
2×2×1¼
2×2×1
2×2×¾ | 60.5
60.5
60.5
60.5
60.5
| 60.5
48.6
42.7
34.0
27.2 | 63.5
63.5
63.5
63.5
63.5 | 63.5
60.3
57.2
50.8
44.5 |
65×65×65
65×65×50
65×65×40
65×65×32
65×65×25 | 2½×2½×2½
2½×2½×2
2½×2½×1½
2½×2½×1¼
2½×2½×1 | 76.3
76.3
76.3
76.3
76.3
| 76.3
60.5
48.6
42.7
34.0
| 76.2
76.2
76.2
76.2
76.2
| 76.2
69.9
66.7
63.5
57.2 |
80×80×80
80×80×65
80×80×50
80×80×40
80×80×32 | 3×3×3
3×3×2½
3×3×2
3×3×1½
3×3×1¼
| 89.1
89.1
89.1
89.1
89.1
| 89.1
76.3
60.5
48.6
42.7
| 85.7
85.7
85.7
85.7
85.7
| 85.7
82.6
76.2
73.0
69.9
|
90×90×90
90×90×80
90×90×65
90×90×50
90×90×40 | 3½×3½×3½
3½×3½×3
3½×3½×2½
3½×3½×2
3½×3½×1½ | 101.6
101.6
101.6
101.6
101.6
| 101.6
89.1
76.3
60.5
48.6
| 95.3
95.3
95.3
95.3
95.3
| 95.3
92.1
88.9
82.9
79.4
|
100×100×100
100×100×90
100×100×80
100×100×65
100×100×50
100×100×40
| 4×4×4
4×4×3½
4×4×3
4×4×2½
4×4×2
4×4×1½
| 114.3
114.3
114.3
114.3
114.3
114.3
| 114.3
101.6
89.1
76.3
60.3
48.6
| 104.8
104.8
104.8
104.8
104.8
104.8
| 104.8
101.6
98.4
95.3
88.9
85.7
|
125×125×125
125×125×100
125×125×90
125×125×80
125×125×65
125×125×50
| 5×5×5
5×5×4
5×5×3½
5×5×3
5×5×2½
5×5×2
| 139.8
139.8
139.8
139.8
139.8
139.8
| 139.8
114.3
101.6
89.1
76.3
60.5
| 123.8
123.8
123.8
123.8
123.8
123.8
| 123.8
117.5
114.3
111.1
108.0
104.8
|
150×150×150
150×150×125
150×150×100
150×150×90
150×150×80
| 6×6×6
6×6×5
6×6×4
6×6×3½
6×6×3
| 165.2
165.2
165.2
165.2
165.2
| 165.2
139.8
114.3
101.6
89.1
| 142.9
142.9
142.9
142.9
142.9
| 142.9
136.5
130.2
127.0
123.8
|
200×200×200
200×200×150
200×200×125
200×200×100
200×200×100
| 8×8×8
8×8×6
8×8×5
8×8×4
8×8×3½
| 216.3
216.3
216.3
216.3
216.3
| 216.3
165.2
139.8
114.3
101.6
| 177.8
177.8
177.8
177.8
177.8
| 177.8
168.3
161.9
155.6
152.4
|
250×250×250
250×250×200
250×250×150
250×250×125
250×250×100
| 10×10×10
10×10×8
10×10×6
10×10×5
10×10×4
| 267.4
267.4
267.4
267.4
267.4
| 267.4
216.3
165.2
139.8
114.3
| 215.9
215.9
215.9
215.9
215.9
| 215.9
203.2
193.7
190.5
184.2 |
