제품 상세 정보
제품 상세스펙
| 규격 | L | L1 | A | A1 | 공차 |
|---|---|---|---|---|---|
| 13*13 | 80 | 36 | 42 | 20 | ±3 |
| 20*13 | 96 | 46 | 45 | 23 | ±3 |
| 20*20 | 96 | 46 | 48 | 23 | ±3 |
| 25*13 | 106 | 56 | 50 | 28 | ±3 |
| 25*20 | 106 | 56 | 53 | 28 | ±3 |
| 25*25 | 106 | 56 | 53 | 28 | ±3 |
| 30*13 | 132 | 63 | 61 | 40 | ±3 |
| 30*20 | 132 | 63 | 57 | 33 | ±3 |
| 30*25 | 132 | 63 | 57 | 33 | ±3 |
| 30*30 | 132 | 63 | 68 | 34 | ±3 |
| 40*13 | 146 | 75 | 68 | 46 | ±3 |
| 40*20 | 146 | 75 | 64 | 40 | ±3 |
| 40*25 | 146 | 75 | 64 | 40 | ±3 |
| 40*30 | 146 | 75 | 74 | 41 | ±3 |
| 40*40 | 146 | 75 | 76 | 41 | ±3 |
| 50*13 | 138 | 51 | 71 | 49 | ±5 |
| 50*20 | 138 | 51 | 67 | 42 | ±5 |
| 50*25 | 138 | 51 | 67 | 42 | ±5 |
| 50*30 | 156 | 69 | 77 | 43 | ±5 |
| 50*40 | 156 | 69 | 79 | 43 | ±5 |
| 50*50 | 156 | 69 | 87 | 43 | ±5 |
| 60*13 | 168 | 68 | 74 | 53 | ±5 |
| 60*20 | 168 | 68 | 71 | 47 | ±5 |
| 60*25 | 168 | 68 | 71 | 47 | ±5 |
| 60*30 | 168 | 68 | 82 | 47 | ±5 |
| 60*40 | 202 | 102 | 85 | 49 | ±5 |
| 60*50 | 202 | 102 | 92 | 48 | ±5 |
| 60*60 | 202 | 102 | 98 | 52 | ±5 |
| 75*30 | 270 | 84 | 86 | 50 | ±5 |
| 75*40 | 270 | 84 | 87 | 50 | ±5 |
| 75*50 | 270 | 140 | 95 | 50 | ±5 |
| 75*60 | 270 | 140 | 102 | 50 | ±5 |
| 75*75 | 270 | 140 | 130 | 58 | ±5 |
| 80*40 | 254 | 95 | 93 | 58 | ±5 |
| 80*50 | 288 | 129 | 101 | 58 | ±5 |
| 80*60 | 288 | 129 | 109 | 60 | ±5 |
| 80*75 | 288 | 140 | 140 | 65 | ±5 |
| 80*80 | 288 | 129 | 145 | 66 | ±5 |
| 100*50 | 286 | 124 | 114 | 71 | ±5 |
| 100*60 | 286 | 124 | 114 | 71 | ±5 |
| 100*75 | 324 | 159 | 153 | 76 | ±5 |
| 100*80 | 324 | 162 | 158 | 79 | ±5 |
| 100*100 | 324 | 162 | 160 | 80 | ±5 |
