Compact Wire Coil Nail Collator
Model Name
CN-90
Series
Wire Weld
View All
Data
CATALOG-ZEUS TECHNO-CN-90
Manufacturer information
provider logo
ZEUS TECHNO

Wire Weld, Plastic Strip, Paper Strip, Rolling Machine, Nail Making Machine

Problem with product info?
Update request
Manufacturer
ZEUS TECHNO
Product Type
Machine
Brand
-
SKU
28641
Product Name
Compact Wire Coil Nail Collator
Model Name
CN-90
Size
-
Weight
-
Product Details

For high speed production of regular wire welded coil nail.
This state of the art collator will produce any type of welded wire coil nails up to 3,000 nails in a coil.
Equipped with automatic coiler & cutter, automatic rubber bander, coating, drying, auto ejection & rotating abstract table.



SPECITIFICATION

Collating Speed
Up to 3,000 Nails per Min.
Nail Size
Length3/4" to 4"(19~100mm)
Diameter.0625" to .148 "(1.60~3.77mm)
Nail SpecAngle0° to 16° Degree
Nails per Coil225 to 400 Nails(Up to 3,000 Nails)
Electric Power30KVA, 3 phase/220V/50~60Hz
Electronic MfgAs Specified by Customer
Pneumatic MfgAs Specified by Customer
Space Required16L x 4.3W x 6H Feet (4,800L x 1,300W x 1,800H mm)
Weight7,700 Lbs (3,500kg)


SAMPLE PRODUCT

Zeus Techno Inc. Compact Wire Coil Nail Collator CN-90
