Nail Maker Machine
Model Name
B-4
Series
Nail Making Machine
View All
Data
CATALOG-ZEUS TECHNO-B-4
Manufacturer information
provider logo
ZEUS TECHNO

Wire Weld, Plastic Strip, Paper Strip, Rolling Machine, Nail Making Machine

Problem with product info?
Update request
Manufacturer
ZEUS TECHNO
Product Type
Machine
Brand
-
SKU
122480
Product Name
Nail Maker Machine
Model Name
B-4
Size
-
Weight
-
Product Details

ㆍConsistent High Speed Production of High-Quality Nails

ㆍPrecise Nail Heads by Using Powerful Hammer

ㆍCommon and Low-Cost Spare Parts, Very Low Maintenance Cost

ㆍSound Deadening Cover, Noise Less WITH Safety

ㆍIncludes Nib Remover

ㆍAvailable Accessories Unit, Powerful Pay-Off



SPECIFICATION

Model B-4
Nail Single Wire (mm, inch) Double Wire (mm, inch)
Cutoff Dia.(mm) 2.2 ~ 4.2mm(.086"~.165")
± 2/100 mm		 2.2 ~ 3.05mm(.086quot;~.120")
± 1/100 mm
Nail Length (mm) 13 ~ 108mm(1/2"~4-1/4") 13 ~ 70mm(1/2"~3-3/4")
Output max. (NPM) Up To 500 NPM Up To 900 NPM
Motor Inverter 7.5 HP 7.5 HP
Machine Weight 3.0 MT 3.0 MT
Floor Space 2.4 x 1.5m (8 x 5ft)

2.4 x 1.5m (8 x 5ft)
