YOUNGJIN WORM

Hollow shaft-Shrink Disc

Model

Series

Precision Worm Reducer

Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Contact the manufacturer/supplier.

Description

DUAL LEAD BOX	35	45	55	63	75	90	110	125
A	86	108	120	134	172	186	220	214
B	110	135	155	173	208	234	276	302
C	44.5	53	61	66	82	91	108	107
D	62	81	90	98	136	141	175	214
E	56	68	78	91	110	130	140	140
F	86	100	112	127	148	170	182	180
G	126	153	175	197	232	264	306	360
H	52.5	62	71	78	94	106	123	135
I(refer)	84	97.5	108	116	140	153.5	177	195
J(h6)	12	15	18	20	24	28	32	35
K	17	20	22	24	28	28	36	45
L	(선택 25페이지 참조)
M	65	85	100	115	130	165	200	185
N(h6)	50	70	80	95	110	130	165	160
O	7	9	9	11	11	13	13	17
P(Max)	73	88	95	105	128	141	158	163
Q	55	67.5	75	84	104	114.5	132	135
R	43	50	56	63.5	74	85	91	111
S	M6	M8	M8	M8	M10	M12	M12	M16
T	45	52	58	65.5	76	87	93	117
T2	69	78	87	96.5	112	126	135	157
U(H7)	20	25	30	35	40	50	60	65
U3	24	30	36	44	50	68	80	80
V	50	60	72	80	90	115	145	145
W	M6	M8	M8	M10	M10	M12	M12	M16
X	35	45	55	63	75	90	110	125
Y	3	3	3.5	3.5	4	4	5	4
WEIGHT(kg)	3.4/3.6	6.2/6.5	8.5/9	13.9/14.6	20.5/21.2	32.5/33.5	46.5/47.8	108

듀얼파워락은 양쪽 파워락을 이용하여 높은 체결력을 얻을 수 있습니다.
