Description Pressure class : JIS 10K/20K, ANSI 150#/300#
Size : 15A to 100A, 1/2" to 4" Material : A105, F304, F304L, F316, F316L,
Other materials available on request End Connection
- RF flange
- FF flange
Option
- Fire safe
- Vacuum service
- NACE
- L port
- T port

Features & Benefits Trunnion mounted ball
Split body, full or reduced bore
Blowout proof stem
Long life stem bearing
Forged body
Fire safe design
Anti-static device
  Application Powder, Slurry service
