Description Pressure class : JIS 10K/20K, ANSI 150#/300#
Size : 15A to 100A, 1/2" to 4" Material : WCB, CF8, CF3, CF8M, CF3M
Other materials available on request End Connection
- RF Flange
- FF Flange
Option
- Vacuum service
- NACE
- High temperature to 350°C

Features & Benefits Floating ball
1 piece, full bore, flanged
Blowout proof stem
Anti-static device
Long life stem bearing
Fire safe design
Actuator mounting pad
  Application Hydrocarbon Process Industry
Water, Oil, Gas Service
