YOOYOUN

YOOYOUN

DISC Type Steam Trap

Model

Series

Steam Trap

Transaction Process

Please contact Komachine.

Payment

Please contact Komachine.

Delivery

Please contact Komachine.

Shipment

Please contact Komachine.

Origin

Please contact Komachine.

Description

STEAM TRAP : TDC-3S


- Fine operating and durability by using the disc and seat with heat treatment.

- Prevent to fault operate due to impurities inner screen.

- This can be used in the equipment needed super small size steam trap.

- Easy adjustment and maintaining because of simple structure.






SPECIFICATION


Category

Content

TYPE

DISC

Meterial

Body

Stainless steel

Trim

Stainless steel

Working Pressure

0.35 ~ 30.0kgf/cm2

0.035 ~ 3.0 MPa

Design temperature

400︒C

Connection Code

JIS B0203 Thread

Fluid

STEAM




DIMENSION


SIZE

L

H

H1

d(PT)

10A

50

40

24

3/8"

15A

80

50

30

1/2"

20A

80

50

30

3/4"

25A

90

55

35

1"

Inquiry
