Earth Leakage Detector, Earth Leakage Relay (Analog-1ch, 2ch type)

Model Name

WYER-21S

Series

Earth Leakage Detector, Earth Leakage Relay

View AllView All Series

Data

ELR_S_TYPE.dwg

Manufacturer information

WOONYOUNG

Various electronic control equipment manufacturer, UL transformer, UL trans, NCT, Reactor, SSR, TPR, SMPS, SPD, Noise filter and more

Inquiry

How to order

Problem with product info?

Update request

Manufacturer

WOONYOUNG

Brand

SKU

132666

Product Name

Earth Leakage Detector, Earth Leakage Relay (Analog-1ch, 2ch type)

Model Name

WYER-21S, WYER-11S, WYER-31S, WYER-21T, WYER-11T, WYER-31T

Size

Weight

Product Details

Model No	WYER-21S WYER-11S WYER-31S WYER-21T WYER-11T WYER-31T
TYPE	1ch
Certification
Rating	AC110~220V
Input	0.2A-0.5A -1.0A 0.1A-0.2A -0.5A 0.03A-0.05A -0.07A-0.1A
Output	1ch
Capacity

Specifications and Features

This earth leakage detector is made for alarm system and trip element with analog system composed of receiver(detector) and zero phase sequence current transformer(ZCT), and primary and secondary circuit. The purpose of this detector
prevents loss of life and various equipments occurred in the accident from the leakage from the electric lines under AC 600V, hence, protects people's properties according to the Fire Service Act (Article 29 clause 3).

ㆍComposing of primary and secondary circuits

ㆍBuilt-in auto detecting ZCT circuit system of disconnection

ㆍAlarming and indicating LED for leakage status of the electric line

ㆍIndicating operation status of leaked circuit and ZCT disconnection

ㆍComposing of manual reset system for leakage of electricline

ㆍBuilt in self-test function for checking out the status of detector
