Ultrasonic Cleaning Machine, Dry, Water, High Pressure Spray, Shuttle Type Washing machine and more
Product features
- Manufactured for washing/coating of various types of products
- Air clamping device installed
- Distancing devices for various types of products can be easily detached and attached
- Exclusive use for automobile brake shoe
Washing Method
- Deeping solvent washing
Washing Process
- Insertion - Ultrasonic - Vapor - Vapor - Blank - Coating - Cooling - Discharge
- Transportation : Cylinder drive
- Used detergent : TCE
- Temperature : 40 ~ 88℃
- Coating unit mixer and freezer installed
- Distancing unit installed before coating
- Air clamp installed to prevent damage from falling products
- Thermal electronic heater method
Product features
- Adequate for washing large quantities of pipe products
- Basket transportation washing
- Tilting device for removing water
- Large drying device
- Automobile air conditioner pipe
Washing Method
- Alkaline ultrasonic wave + Water
Washing Process
- Insertion - Alkaline Ultrasonic Wave - Alkaline Ultrasonic Wave - Rinse Bubble - Rinse - Air Spray - Hot Blow - Discharge
- Geared motor + Cylinder operation
- Used detergent : Alkali or Water
- Temperature : 60℃
- Curculation pump : 1 ~ 2 Bar
- Filter housing : 5 ~ 50 Micro (select)
- Oil skimmer installed
- Drying facility : Electric heater method
Product features
- Automatic basket transportation type
- Pure washing method is adequate for erasing smudges and for higher cleanliness (SUS products, fuel battery, glass, cell phone parts)
- Automatic transporter drying equipment installed on discharging conveyor
- Pure manufacturing facilities are attached
- Energy-saving function is turned on when products are not inserted
- Automobile parts, electronic parts, injection mold parts, other products requiring high levels of cleanliness
Washing Method
- Pure ultrasonic wave wash/dry method
Washing Process
- Insertion - Ultrasonic Wave - Ultrasonic Wave - Rinse - Rinse - Spray Wash - Air Spray - Dry and Discharge
- Four-axes transportation : Geared motor transportation
- Used detergent : Pure, Alkaline detergent
- Filtering pump
- Filter housing : 5 ~ 50 Micro (select)
- Pure manufacturing device : 500~1,000 Liter/Hr
- Pure storage tank installed
Product features
- Automatic basket transportation type
- Water-soluble washing method
- Products requiring anti-rust treatment
- Adequate for products requiring high levels of cleanliness
- Energy-saving function is turned on when products are not inserted
- Washing automobile parts, electronic parts, - injection mold parts
Washing Method
- Water-soluble ultrasonic washing/drying method
Washing Process
- Insertion - Ultrasonic Wave - Ultrasonic Wave - Rinse - Rinse - Anti-Rust - Air Spray - Hot Blow - Hot Blow - Discharge
- Four-axes transportation : Geared motor + Cylinder
- Used detergent : Water-soluble detergent and anti-rust solvent
- Filtering pump
- Filter housing : 5 ~ 50 Micro (select)
- Heater unit : 2set
- Automatic basket transportation conveyor
Product features
- Automatic basket transportation type
- Solvent washing method is adequate for washing semiconductor parts and fuel battery
- Discharging conveyor has automatic transportation drying facility installed
- Energy-saving function is turned on when product is not inserted
- Semiconductor parts, electronic parts, injection mold parts, and other products requiring high levels of cleanliness
Washing Method
- Solvent ultrasonic washing/drying method
Washing Process
- Insertion - Ultrasonic wave - Ultrasonic wave - Rinse - Drying - Idle - Dry and discharge
- Four-axes transportation : Geared Motor Transportation
- Used detergent : TCE, MC
- Filtering Pump
- Filter Housing : 5 ~ 50 Micro (Select)
- Cooling unit and storage tank installed
