Product features

- Automatic basket transportation type

- Designed to wash/dry parts that are difficult to wash/dry or are adhesive

- Electricity-saving function turned on when products are not inserted

- Vacuum distillation unit and freezing facility are integrated as one base; layout changes can be easily conducted

- Chloride replacement solvent is used

Application

- Automobile parts, electronic parts

Washing method

- Vacuum ultrasonic washing/drying method

Washing Process

- Insertion – Vacuum Ultrasonic Wave – Vacuum Rinse Ultrasonic Wave – Ultrasonic Drying - Discharge

Specifications

- Vacuum degree : 1 Torr

- Wash/Dry temperature : 20 ~ 120℃

- Heat source : Steam or heater

- Filter Housing : 5 ~ 50 Micro (select)

- Vacuum distillation unit : 100 Liter/Hr

- Freezer : 10 R/T

- Service tank installed
