Product Name
Carbon Dioxide Sensor
Model Name
PoC2021-3
Size
-
Weight
-
Product Details
A carbon dioxide sensor with accurate measurements
Indoor air quality management is important for a healthy and pleasant life.
More accurate carbon dioxide measurements using the NDIR method can help manage indoor air quality comfortably.
OVERVIEW
A more accurate carbon dioxide sensor using the NDIR method.
 |
 Non-Dispersive Infrared Rays |
 Strong Durability |
 Real-time Measurement |
MADE IN KOREA
Developed / Produced 100% in Korea
The product is developed, produced, and managed 100% in Korea with rigorous quality management and reliable A/S.
SPECIFICATIONS
| Model | PoC2021-3 |
| Measurement Range | 400 ~ 5000 ppm |
| Resolution | 1 ppm |
| Maximum Consistenct Error | ±(50ppm+3%Reading) |
| Time to first reading | ≤30 seconds |
| DC Power Supply | Typ:5.0 V / Min:4.5 V / Max: 5.5 V |
| Active Current | 200mA peak , 25mA average |
| Interface Level | L <0.8 @3.3 H >2.7@3.3 |
| Working Temperature Range | -5~50 ℃ |
| Working Humidity Range | 0~85% non condensed |
| Storage Temperature Range | 40~+85℃ |
| Life Time | ≥7 years |
| Physical Size | 33×20×10.5 mm |
| Weight | 5.7g |
| Pin Gap | 2.54 mm |
