Millenium Optical System
Polarizing Beamsplitter Cube Coatings
Model
Series
Cootings
Transaction Process
Please contact the manufacturer/supplier.
Payment
Contact the manufacturer/supplier.
Delivery
Contact the manufacturer/supplier.
Shipment
Contact the manufacturer/supplier.
Origin
Contact the manufacturer/supplier.
Description
Polarizing Beamsplitter Cube Coatings are deposited between two comented right angle prisms. They are designed to separate an incident beam into S and P polarization components with an extinction ratio (TP/TS) in excess of 500 : 1 (1000: 1 for 400nm - 2.0 ㎛).The incident energy is split into two orthogonally polarized beams that emerge at 90。with respect to each other. These coatings are also useful for combining two orthogonally polarized beams.
*For UV and high power applications, go to high power plate beamsplitter on page 21.
These and other coatings are available from stock on a variety of substrates. Other wavelengths and angles of incidence can be provided upon request. Please contact us for assistance with fulfilling your requirements.
