Features

→ It only consists of plate and pin, and the chain satisfies ANSI standard
→ Used to operate devices that require irregular movement at gentle speed
→ It is used in all industrial facilities that require safe and strong device to transfer up and down or horizontal pulling motion of heavy equipment because it can transport large quantity of heavy objects despite narrow width

→ Major areas of use:

    Forklift, machine pulling, hydraulic / pneumatic jack auxiliary apparatus, remote control device, balancing device for sliding door, etc.

 Details

→  A Type Leaf Chain
    Number of inner plate links and pin link plates is identical
    External shape and thickness of plate, and outer diameter of pin are identical to roller chain with same pitch
    Plate alignment and dimensions of A and B type leaf chains can be changed according to order

→ B Type Leaf Chain (Strong Type)
    Assembled with more junction link plates than pin links
    Exterior of plate is identical to roller chain, but thickness of plate and outer diameter of pin are made as identical to roller chain with pitch 1 size larger, increasing breaking strength and allowable load
