You save valuable time when transporting goods with the ERE 120n: with a higher speed in ride-on mode compared with solely pedestrian-operated trucks, goods can be cost-effectively transported over greater distances.

The compact ERE 120n is specially designed for very confined spaces such as HGVs.

Just folding in the stand-on platform and side supports is enough for the ERE 120n to take the tightest corner.

For intensive operation over long distances or on ramps, batteries with capacities up to 375 Ah are available.

Where schedules require the operation of more than one shift, the 375-Ah battery can be removed from the side (optional) in order to facilitate a faster battery exchange.

✔ ShockProtect to protect the operator, truck, and load

✔ Maintenance-free 3-phase AC motor gives high productivity

✔ Compact design for flexible usage

✔ ProTracLink suspension for high stability

✔ Multiple shift operation due to lateral battery exchange (optional)

Features

Compact construction for every application

Utilization in confined spaces with narrow frames (700 mm) and short frame lengths.
Safe operation even with heavy loads thanks to robustly designed support arms.
Low-fatigue operation with an ergonomically designed tiller arm that has low steering forces.

Long operating times

Short version: 2 PzS 250 Ah
Long version: 3 PzS 375 Ah

Reduced maintenance

Low wear on side support wheels via leveling adjustment when approaching a ramp at an angle: a mechanical link ensures both support wheels are always at the same height. In contrast to a spring-loaded support wheel, they do not hit anything and thus are not damaged.
Enclosed wheel rims exclusive to Jungheinrich ensure a long service life for load wheels, even in the toughest applications.

Optimum travel characteristics

Sprung-loaded side support wheels – connected via ProTracLink, ensure safe and stable operation in all applications.
Jungheinrich ShockProtect – protection for operator, truck, and load via sprung-loaded drive. The sprung-loaded system reduces vibrations for the operator and frame.

Well-informed at any time

CanDis information display (optional) with additional operating hour display and service code memory.
Truck activation via PIN code using CanCode (optional).
Further adjustment of drive parameters (optional).

The high-performance drive motor and “intelligent”

The travel speed is maintained in every travel situation, especially on gradients.
The ERE brakes automatically in the event of unintentional roll-back on ramps.
Energy recovery through regenerative braking on travel speed reduction.

Flexible options

Design 1: folding stand-on platform with side support arms: choice between pedestrian and ride-on operation; reduced travel speed (6.0 km/h) with side support arms folded in.
Design 2: Fixed stand-on platform with enclosed support guards (optional): Exclusively for applications without pedestrian operation; safe standing with side protection; with 375-Ah battery compartment.

Other options

Lateral battery exchange.
Cold store design.

Model Overview

Model	Load capacity	Lift height	Travel speed	Overall length	Battery voltage
ERE 120n	2,000 kg	122 mm	8.5 km/h	1,832 mm	24 V
