Product Name Ultrasonic cleaning system - Multi tank type
Model HSW3-1/4-1
Series Products
Catalog
Product Description



Hanshin Tech Ultrasonic cleaning system - Multi tank type HSW3-1/4-1

This cleaner is designed to efficiently clean foreign substances (organic or inorganic compounds) off the object to be cleaned.
It also dries quickly by harmonizing the physical and chemical synergism between the ultrasonic waves and cleaning solution through the selection and use of a combination of cleaning methods, including immersion, ultrasonic, rinsing, steaming, and injection according to use.

These kinds of washers are classified as water-soluble cleaners or organic solvent cleaners depending on the type of detergent.



Specifications of 3-tank water soluble cleaner

Process : Ultrasonic cleaning - rinsing
- hot air drying

MODELHSW3-1
TANK (L*W*H)450*450*300
Ultrasonic1200W
Capacity60ℓ
Pump1/4HP
Filter10"*100㎛
Heater3KW*2EA
Pin Heater3KW



Specifications of 4-tank water soluble cleaner

Process : Ultrasonic cleaning - rinsing
(Ultrasonic cleaning) - rinsing - hot air drying

MODELHSW4-1
TANK (L*W*H)450*450*300
Ultrasonic1200W
Capacity60ℓ
Pump1/4HP
Filter10"*100㎛
Heater3KW*3EA
Pin Heater3KW



Hanshin Tech Ultrasonic cleaning system - Multi tank type HSW3-1/4-1 1

This cleaner is designed to efficiently clean foreign substances (organic or inorganic compounds) off the object to be cleaned.
It also dries quickly by harmonizing the physical and chemical synergism between the ultrasonic waves and cleaning solution through the selection and use of a combination of cleaning methods, including immersion, ultrasonic, rinsing, steaming, and injection according to use.

These kinds of cleaners are classified as water-soluble cleaners or organic solvent cleaners depending on the type of detergent.



Specifications of 3-tank organic solvent cleaner

Process : Ultrasonic cleaning - rinsing - Steam Drying

MODELHSU3-1HSU3-2HSU3-3
TANK (L*W*H)350*300*250400*350*250450*400*250
Ultrasonic600W1200W1200W
Capacity26ℓ35ℓ45ℓ
Heater2KW*4EA2KW*4EA2KW*4EA
Cooler3RT3RT3RT



Specifications of 4-tank organic solvent cleaner

Process : Ultrasonic cleaning - rinsing(Ultrasonic cleaning) - rinsing - Steam Drying

MODELHSU4-1HSU4-2HSU4-3
TANK (L*W*H)350*300*250400*350*250450*400*250
Ultrasonic600W1200W1200W
Capacity26ℓ35ℓ45ℓ
Heater2KW*3EA2KW*3EA2KW*3EA
Cooler3RT3RT3RT
