Treatment results obtained so far have demonstrated that shock wave therapy provides improved blood circulation in the treated pain regions and that a long-term stimulation of metabolism is achieved in areas which, by nature, are poorly supplied with blood. Since repeated treatment sessions have shown to increase the beneficial effects of shock wave therapy, there is every reason to assume that shock waves also produce secondary effects as described in the hpothesis towards associative pain memory, for instance.

▶  Specifications
 Power Supply: AC 220, 50/60Hz
 Power Consumption : 700VA
 Output Pressure : Max 6bar
 Pulse Energy : Max 1.6mJ
 Spot Size : fx=21mm, fy=15mm
 Striking Energy Density : Max 0.013mJ/sq.mm
 Operating Pulse : once/1 pushing button, 3, 5, 10 times/sec
 Number of Operating Times : 1000, 2000, 3000, continuous
 Dimension : 570 × 540 × 1240(H)mm 65Kg
