DAEHWA ENGINEERING

DAEHWA ENGINEERING

Holizontal type

Model

Series

Float type level switch


Transaction Process

Please contact Komachine.

Payment

Please contact Komachine.

Delivery

Please contact Komachine.

Shipment

Please contact Komachine.

Origin

Please contact Komachine.


Description

Operating principle

Two permanent magnets which react on each other are separately fixed at the end of the float arm and inside terminal box.
The float and the arm move up and down with liquid level.
The float movement by liquid level is transmitted through two magnets to the micro switch Which is linked with a magnet inside the terminal box. And the micro switch sends ON-OFF alarm signals.


Application


Fresh water tank, Heavy Fuel oil tank, D.O tank, Sludge tank, Sewage tank, etc.


Technical date

Contact : electrical micro switch, change contact,
SPDT, DPDT
Switch rating : AC 250V/15A, AC 480V/15A,DC 30V/6A Max. Working Pressure : 10kg/㎠
IP Rating : IP 56, IP 68(option)
Installation : horizontal
Material - Terminal Box : ALDC, SS400
- Flange : SS400
- Float : SUS316, Synthetic Rubber


Contact Composition




LS-SM-D1




LS-SM-D3-
