Description
Description
ㆍ360° rotation device makes the job convenient and more efficient.
ㆍOutstanding design allows the primary and secondary demolition work at same time.
ㆍHigh performance and easy pulverization in narrow space.
ㆍLonger durability with Hardox steel.
ㆍSpeed up valve can be installed at option.
Spectification
| ITEM/MODEL | FR500R | FR700R | FR1000R | |
| Operating Weight | kg | 1,600 | 1,900 | 2,800 |
| lb | 3,527 | 4,189 | 6,173 | |
| Operating Pressure | kg/㎠ | 320 | 320 | 320 |
| psi | 4,551 | 4,551 | 4,551 | |
| Max. Opening Width | mm | 720 | 830 | 950 |
| inch | 28.35 | 32.68 | 37.40 | |
| Crushing Force | ton | 90 | 115 | 138 |
| Cutting Force | ton | 170 | 200 | 270 |
| Cutter Length | mm | 150 | 180 | 180 |
| inch | 5.91 | 7.09 | 7.09 | |
| Overall Length | mm | 2,300 | 2,400 | 2,700 |
| inch | 90.55 | 94.49 | 106.30 | |
| Overall Height | mm | 1,144.5 | 1,200 | 1,463 |
| inch | 40.06 | 47.24 | 57.60 | |
| Overall Height | mm | 710 | 710 | 810 |
| inch | 27.95 | 27.95 | 31.89 | |
| Suitable Excavator | ton | 15~24 | 20~30 | 26~40 |
Remark
Above specifications are subject to change without notice.
Hydraulic Motor Spectification
| ITEM/MODEL | FR500R(S) | FR700R(S) | FR1000R(S) | |
| Revolution | rpm | 5~12 | 5~12 | 4~10 |
| Oil Flow | ℓ/mim | 40~60 | 40~60 | 40~60 |
| Operating Pressure | kg/㎠ | 40~160 | 40~160 | 40~160 |
| psi | 568~2275 | 568~2275 | 568~2275 | |
