MODEL NO.

UINT

TK-2105B

TK-3105B

TK-4106B

TK-4110B

TK-5109B

TK-6110B

BLOCK SIZE

L*H*W(㎜)

2000*1000
*500

3000*1000
*500

3600*1200
*600

4000*1000 *1000

5000*1200
*900

6000*1200
*1000

MOLD VOLUME

㎜

1.07

1.60

2.73

4.18

5.63

7.49

CYLINDER

￠(㎜) x EA

125x2

63x2

63x4

80x4

80x4

80x4

HYDRAULIC CLAMP

￠(㎜) x EA

100x4(AIR)

50x4

50x6

50x6

63x6

63x8

HOPPER CAPACITY & FEEDER

ℓ x EA

1500x4

2000x6

3000x8

4500x10

6000x12

8000x14

STEAM PIPE

￠(㎜)

100

135

150

150

200

250

AIR PIPE

￠(㎜)

25

25

32

32

40

50

DRAIN PIPE

￠(㎜)

80

100

100

125

150

150

HYDRAULIC MOTOR

㎾

AIR

7.5

7.5

7.5

7.5

11.0

VACUUM SYSTEM

VACUUM
PUMP(㎾),㎥

11.0, 1.0

11.0, 1.5

11.0x2, 1,5

11.0x2, 2.0

15.0x2, 2.0

18.5x2, 3.0

SUCTION
PUMP(㎾)

7.5

7.5

7.5

7.5

10.0

10.0

POWER

㎾

11.0

18.5

29.5

29.5

37.5

48

MACHINE SIZE

HORIZONTAL L*W*H(㎜)

3500*2400 *4500

5100*2500 *4500

7500*2700 *4750

8000*2500 *4750

8800*2700
*5000

11000*3700
*5000

VERTICAL
L*W*H(㎜)

2800*1200 *2400

2800*1200 *3800

3000*1400 *4200

3000*1400 *4600

3500*1400
*5600

-

WEIGHT

ton

5.0

6.8

7.6

8.0

9.5

12.0
