제품 상세 정보
| Specification | |
|---|---|
| Length of Rotor | 1.2M |
| Diameter of Rotor | 0.4M |
| Cutting Diameter | 0.493M |
| RPM of Rotor | 118 |
| Cutting Speed | 3.06 M / sec |
| Knives | 15Rotor Knives |
| Knives | 16 Stator Knives |
| Motor | 132Kw, 1480rpm, 50Hz |
| Gear Type | Heavy Duty Planet Gear |
| Gear Ratio | 5.1 : 1/td> |
| Chain Type | 2” Triplex |
| Chain Wheel | Z = 31 / 76 |
| Capacity | 5-6ton / Hr |
| Weight | Approx. 18,000Kg |
| Granule Particle Size | 16~20mm |
| Quantity | 1 Sets |
