Production capacity : up to 120 batteries per hour
Range of application : For heat sealing of battery containers and covers of polypropylene.
 Heat sealing without Teflon is possible.
Battery Capacity up to max. : 2Volt, container height 250~720mm
Battery size up to max. : 260Lx200Wx750Tmm
Cycle Duration : 1minute
Standard electrical : 220/380V, 3phase, 60Hz or as required.
Electric consumption : Heating plate- 380V, 4kw
                                         Conveyor Motor - 380V, 0.2kw
                                         Screw motor for height control of each battery : 380V, 0.4kw
Dimension : 1,500Lx1,100Wx1,770Hmm
Weight : 1,200kg
