Features

• 3D map developed with SAMYUNG ENC’ s / NAVIONICSⓡ proprietary technology
• High intensity and high definition display with high resolution TFT Applied
• LED backlighting adjustable to 10 different brightness levels
•  NAVIONICSⓡ Platinum+ available utilizing SD card input
•  Plays movies, videos and music from SD or USB input
• 512/1024MB internal memory and embedded with standard SAMYUNG S-MAP
• Individual navigation GOTO & MOB buttons
•  NMEA(0183/2000) interface (AIS, NAVTEX, DSC, Data repeater, Fuel control etc.)
• Multiple language support (English, Chinese, Russian, etc.)
•  DGPS (including WAAS, MSAS, EGNOS) provide greatest accuracy possible
• Excellent user friendly menu and icons
• Perfect navigational interface with Auto Pilot / Engine Controls
• Utilizes dual frequency system (50/200 kHz) for detection of small fish groups (NF80)
• Features upgraded auto range, gain output and pulse length in our latest fish finding circuitry (NF80)
• Utilizes high performance transduce for detection of individual and small fish (NF80)

Specifications

▶ N80/N100/N120
• Display : 8” /10.4” (800 x 600 pixels) / 12.1” (1024 x 768 pixels) LED Backlight
• Receiving channel & Tracking satellite : 50 Channels 16 Satellites / Digital 16 Channels multi-tracking type
• Supply voltage : 11 to 35 V DC Approx. 40W
• Operating temp. : -10°C ~ 50°C
• Display mode : normal, true-motion, course-up, northup, head-up function
• Alarms : Arrival radius, anchor, XTE, danger, too shallow, too deep, fish, temperature, temperature rate,
   low battery, low fuel(optional), loss of DGPS fix, radar guard zone, dangerous AIS vessels.
• Chart/User card : SAMYUNG 2D/3D, NAVIONICSⓡ Platinum+ / SD Card 2 slot, USB 1slot
• Waypoints : 30,000 waypoints (Event Mark : 48, Mark Color : 16)
• Routes : 100 Routes, with up to 100 points each
• Tracks : By time or distance, 10 tracks of 30,000 points
• Chart datums : 216 Chart datums(1/2000~1/37,500,000)
• Chart scale : 0.2 ~ 500 nm
• Interface : NMEA 0183, NMEA 2000

▶ NF80/NF100/NF120
• Display : 8” /10.4” (800 x 600 pixels) / 12.1” (1024 x 768 pixels) LED Backlight
• Receiving channel & Tracking satellite : 50 Channels 16 Satellites / Digital 16 Channels multi-tracking type
• Supply voltage : 11 to 35 V DC Approx. 40W
• Operating temp. : -10°C ~ 50°C
• Display mode : normal, true-motion, course-up, northup, head-up function
• Alarms : Arrival radius, anchor, XTE, danger, too shallow, too deep, fish, temperature, temperature rate,
   low battery, low fuel(optional), loss of DGPS fix, radar guard zone, dangerous AIS vessels.
• Chart/User card : SAMYUNG 2D/3D, NAVIONICSⓡ Platinum+ / SD Card 2 slot, USB 1slot
• Waypoints : 30,000 waypoints (Event Mark : 48, Mark Color : 16)
• Routes : 100 Routes, with up to 100 points each
• Tracks : By time or distance, 10 tracks of 30,000 points
• Chart datums : 216 Chart datums(1/2000~1/37,500,000)
• Chart scale : 0.2 ~ 500 nm
• Interface : NMEA 0183, NMEA 2000
• Frequency : 50/200KHz
• Output : 600W/1KW
• Depth Range : 3m~1,500m
• Color Display : 16 colors
• Brightness : 10-step
• Screen Moving Speed : super fast, fast, medium, low, stop
• Battery Voltage Display : Voltage number dispaly
• AUTO GAIN Adjustment : OFF/ON
• A-Mode Display : OFF/ON
• Demo Dispaly : OFF/ON
• Weak Color Removal : 0% ~ 75%
