Features
• Wide 5" High resolution TFT LCD
• Fast screen response by high performance CPU
• 10 steps adjustable LED backlight
• Multiple languages available including English, Chinese, Russian,Thai, Malay etc.
• 128MB internal memory and built-in standard Samyung chart
• DGPS(WAAS, MSAS, EGNOS)
• User-friendly operation type by using icon for each menu
• NMEA 0183 interface (AIS, NAVTEX, DSC etc.)
• 4 split screens (Chart, Data, Highway etc.)
• Suitable for small fishing boat
• Using single (200Khz,300W) & dual(50/200Khz,600W) frequency for detection of small and individual fish
• Easy to use by auto gain
Specifications
• Size : 140 mm(H) x 190 mm(W) x 81.3 mm(D)
• Display : Wide 5”, TFT color, 800 x 480 pixels
• Supply voltage : 10 to 32 V DC
• Operating temp. : -10℃ ~ 50℃
• Alarms : Arrival radius, anchor, XTE, danger, too shallow, too deep, fish,temperature, temperature rate,low battery, low fuel(optional),loss of DGPS fix, radar guard zone, dangerous AIS vessels.
• Chart/User card : NAVIONICS® GOLD /Micro SD Card
• Waypoints : 10,000 waypoints (Event Mark : 48, Mark Color : 16)
• Routes : 100 Routes, with up to 100 points each
• Tracks : By time or distance, 10 track of 15,000 points
• Chart datums : 216 Chart datums (see next page)
• Chart scale : 0.2 ~ 500 nm
• Interface : NMEA 0183 (2 port)
• Frequency : 200KHz
• Output : 300W
• Depth Range : Min : 0m~3m, Max : 0m~1500m
• Color Display : 16 colors
• Brightness : 10-step
• Screen Moving Speed : super fast, fast, medium, low, stop
• Battery Voltage Display : Voltage number dispaly
• AUTO GAIN Adjustment : OFF/ON
• A-Mode Display : OFF/ON
• Demo Dispaly : OFF/ON
• STC : 0%~75%
