Chemical Injection Unit

Our deliveries include:

Pump skids

Tank skids

Chemical Injection Unit – CIU

Multipurpose Chemical Injection Systems

MEG / Methanol Injection Skids

Chemical Dosing Panels

CIP (Chemical Injection Package) / HIP (Hypochlorite Injection Package)

Our injection(dosing) package is used to inject certain chemicals in to areas where they are requried.

The main industrial areas for the dosing/injection packages designed and produced are Oil & Gas (on-shore, off-shore, FPSO), Petrochemical, Energy (boilers, desalination, cooling towers).

The Package can be for single injection output or muliti chemical systems and the pumps used are accoding to API 674 / API 675 latest edition. They can be either diaphragm type or plunger pump with manual or automatic stroke control. These pumps can either be electrically operated or air operated. The pressure and flow rates can be customized according system design requirements calibration pots or calibration gauges for the accurate setting of the pumps are provided and pulsation damper can be situated at along the discharge to remove any pulsation generated by the pumps.

The chemical storage tanks needed to strore the chemicals can be made of SS316, SA36 or GRP and is usually mounted on a common skid with the pumps. the tanks shall cme with level gauges, level transmitters etc as part of the instruments.

If the complete package is placed in a hazardous environment, the electrical equipment and instruments shall come with the relevant ATEX certificates.

Most Common Applications are as follow.
▪ Corrosion Inhibitor, Antiscale, Antifoam, Hypochlorite injections, MEG injection, DEG Injection, Glycol Injection, Demulsifier.
