MODEL NO.

BW2M2812CS

Effective Lens Aperture

Front

-

Rear

-

Focal Length

2.8~ 10.0

Back Focal Length

8.04 ~ 17.66In Air

F-no

1 : 1.2

Mechanical BFL

12.5 In Air

Sensor Size

1/2.7"

Mount Type

CS Mount

Operation

Iris

AUTO (F1.2~360)

Dimensions

Ø48.5 x 61.3

Focus

-

Weight

92g

Object Size at 50cm

2.8mm

-

Objective Dimension at M.O.D

-

10.0mm

-

Angle of View

D

1/2.7"

139.1°~ 33.4°

Remarks
Element :＊1Aspherical Glass
               *Image Circle : Ø6.62

               *2Mega Pixel

H

118.3°~ 29.1°

V

63.6°~ 16.5°

IRIS

Drive

190Ω

Damping

855Ω
