제품 상세 정보
※ Cover Option
● Rating : 250V 10A
● Insulation Resistance : More Than 1000MΩ DC 500V
● Withstand Voltage : AC2000V Per Minute
● Wire Size / Range : AWG18~26
● Maximum Acceptable Temperature : -40°C ~ +85°C
|
No |
Component Part |
Material |
Standard |
Plated |
Remark |
|
1 |
Frame |
P.B.T. |
UL94V-0 |
- |
- |
|
2 |
Base |
P.B.T. |
UL94V-0 |
- |
- |
|
3 |
Terminal Pin |
BRASS |
C2680 t0.8 |
Sn |
- |
|
4 |
Terminal #1 |
PHOSPHOR BRONZE |
C5210 t0.3 |
Ni |
- |
|
5 |
Terminal #2 |
PHOSPHOR BRONZE |
C5210 t0.35 |
Ni |
- |
|
6 |
Screw |
SWCH10A |
M3 * 6 |
Ni |
- |
|
7 |
Washer |
SPCC |
6 * 6 |
Ni |
- |
|
8 |
Lock Screw |
SWCH10A |
M3 * 9.5 |
Ni |
- |
|
9 |
Rec Nut |
SWCH10A |
6*6* t2.0 |
Ni |
- |
|
10 |
Insert Nut |
BRASS |
M3 |
Ni |
- |
|
11 |
E-Ring |
SUP |
0.4t |
Ni |
- |
|
12 |
Cover |
PC |
141R-701 |
- |
- |
