제품 상세 정보
● Rating : 300V 30A
● Insulation Resistance : More Than 1000MΩ DC 500V
● Withstand Voltage : AC2000V Per Minute
● Wire Size / Range : AWG12~20
● Maximum Acceptable Temperature : -40°C ~ +85°C
|
No |
Component Part |
Material |
Standard |
Plated |
Remark |
|
1 |
Frame |
P.B.T. |
UL94V-0 |
- |
- |
|
2 |
Terminal #1 |
BRASS |
C2680R |
Sn |
- |
|
3 |
Terminal #2 |
BRASS |
C2680R |
Sn |
- |
|
4 |
Screw |
SWCH10A |
- |
Zn3+ |
M5 * 11 |
|
5 |
Screw |
SWCH10A |
흑착색 |
M5 * 11 |
|
|
6 |
P/WASHER, S/WASHER |
SPCC/HSWR62 |
Zn3+ |
10.7 * 10.7 / Ø 6.7 |
|
|
7 |
P/WASHER, S/WASHER |
SPCC/HSWR62 |
흑착색 |
10.7 * 10.7 / Ø 6.7 |
