STW-B
Model Name
STW-B
Series
Triple Insulation Wire
Data
-
Manufacturer information
provider logo
YOUNG CHANG

Special cable manufacturer, Thermal resistance wire, Heating cable, Thermal resistance tube, Insulated wire, Wire for aviation

Problem with product info?
Update request
Manufacturer
YOUNG CHANG
Product Type
Machine
Brand
-
SKU
37804
Product Name
-
Model Name
STW-B
Size
-
Weight
-
Product Details

ย

1. Description

The Triple Insulation Wire (STW Series) which is manufactured by Young Changย is designed to fulfill the requirement of Class B thermal index. STW-B is the insulated winding wire having reinforced insulation complying with subclause 2.9.4.4 Annex U of IEC 60950 and subclause 2.10.5.4, Annex U of IEC. STW-B makes a merit of needing no interlayer insulation material such as insulation tape or barrier tape, thereby downsizing transformers a great deal, bringing about high efficiency and cost cutback. Easier to design environmentally friendly transformers which can be easily disassembled and recycled. It is anticipated that Young Chang Siliconeโ€ฒs STW-B will play a role in a widening range of fields.

ย

ย

2. Application

- Battery charger of electric device
- Down-sized switching transformers

ย

ย

3. Certification

ย  UL 1950 / 2352 / 60950
ย  CSA C22,2 No.1 / 950 C/A Notice 15A
ย  BSI EN 60065 / EN60950 / IEC 60065 / IEC 60950
ย  TUV EN 60950 / 60065
ย  NEMKO EN 60950
ย  VDE EN 60950 / IEC 60950

ย

ย (1) Exclusive Agent

ย ย

ย ย ย - ITACA :ย Exclusive Agent in Europe ย

ย ย ย ย

ย ย ย ย ย ย ย ย ย ย ย ย

4. Wire Construction

ย (1) Annealed Copperย
ย (2) PET insulationย
ย (3) PET insulationย
ย (4) Nylon insulation

ย

ย

5. Specification

Rated Temperatureย  105 ~ 130โ„ƒ (B-Class)
Rated Voltย  1,000Vrms(Maximum) 'sย
Conductor Sizeย  0.20mm ~ 1.0mm (32~18 AWG)ย
Solderabilityย  1ย Solderable without strippingย
