This product is manufactured by

YOUNG CHANG

Website

+82 2-808-2777

This product is manufactured by

YOUNG CHANG

M22759-84

Model Name

M22759-84

Series

Wire for Airplane

View AllView All Series

Data

Manufacturer information

YOUNG CHANG

Special cable manufacturer, Thermal resistance wire, Heating cable, Thermal resistance tube, Insulated wire, Wire for aviation

Inquiry

How to order

Problem with product info?

Update request

Manufacturer

YOUNG CHANG

Product Type

Machine

Brand

SKU

37811

Product Name

Model Name

M22759-84

Size

Weight

Product Details

1 - Conductor : Nickel-Plated Copper
2 - Insulation : Fluoropolymer/polyimide tapes

1. Description

As a result of continuous research and development, Young Chang obtained the MIL Certificate in 2012.

MIL wire obtained U.S.A department of State (Registeration : QPL-SIS-22759-25)

Mil wire can adapt to commercial or military airplane, because of superiority of miniaturization, lightening, heat resistance and chemical resistance.

2. Production Standard

Part Number	AWG size	Conductor Stranding	Approx. LBS/MFT	Min O.D. (in)	Max O.D. (in)
M22759/84-2	2	665/30	227.0	0.360	0.380
M22759/84-1	1	817/30	295.0	0.400	0.420
M22759/84-01	1/0	1045/30	351.0	0.442	0.462
M22759/84-02	2/0	1330/30	432.0	0.498	0.528
M22759/84-03	3/0	1665/30	542.0	0.554	0.584
M22759/84-04	4/0	2109/30	689.0	0.615	0.655
