Overview
- Summary
- A comprehensive valve specialist, manufacturing self-actuated control valves for piping fluid control, offering energy-saving and eco-friendly solutionsA comprehensive valve specialist, manufacturing self-actuated control valves for piping fluid control, offering energy-saving and eco-friendly solutions
- Key Products/Technologies
- Pressure Reducing Valves/Drain Separators: The GD-200 model, a direct-acting type for water, oil, air, and non-dangerous fluids, with nominal sizes 15A-150A, maximum inlet pressure 1.0 MPa, reduced pressure range 0.05-0.7 MPa, and maximum temperature 80°C specifications. The GP-27 model, a pilot-operated type for steam, with nominal sizes 125A-200A, inlet pressure 0.1-1.0 MPa, reduced pressure range 0.03-0.8 MPa, and maximum operating temperature 220°C features. The GP-1000 model, a pilot-operated piston type for steam, offering superior durability, stable performance, ANSI Class IV valve leakage compliance, and a high reduction ratio of 20:1. The GP-2000 model, a pilot-operated diaphragm type for steam, providing large capacity and high accuracy, with nominal sizes 15A-200A, inlet pressure 0.1-2.0 MPa, reduced pressure range 0.02-1.7 MPa, and maximum temperature 220°C specifications.Pressure Reducing Valves/Drain Separators: The GD-200 model, a direct-acting type for water, oil, air, and non-dangerous fluids, with nominal sizes 15A-150A, maximum inlet pressure 1.0 MPa, reduced pressure range 0.05-0.7 MPa, and maximum temperature 80°C specifications. The GP-27 model, a pilot-operated type for steam, with nominal sizes 125A-200A, inlet pressure 0.1-1.0 MPa, reduced pressure range 0.03-0.8 MPa, and maximum operating temperature 220°C features. The GP-1000 model, a pilot-operated piston type for steam, offering superior durability, stable performance, ANSI Class IV valve leakage compliance, and a high reduction ratio of 20:1. The GP-2000 model, a pilot-operated diaphragm type for steam, providing large capacity and high accuracy, with nominal sizes 15A-200A, inlet pressure 0.1-2.0 MPa, reduced pressure range 0.02-1.7 MPa, and maximum temperature 220°C specifications.
- Steam Traps/Air Traps: The TSF-8-21 float steam trap, a threaded type DN25, capable of reliable condensate removal up to 21 bar g, with a maximum throughput of 2 tons per hour, and versatile horizontal and vertical mounting options. Thermodynamic steam traps, featuring a simple and compact disc-only moving part structure, for efficient discharge of air and condensate.Steam Traps/Air Traps: The TSF-8-21 float steam trap, a threaded type DN25, capable of reliable condensate removal up to 21 bar g, with a maximum throughput of 2 tons per hour, and versatile horizontal and vertical mounting options. Thermodynamic steam traps, featuring a simple and compact disc-only moving part structure, for efficient discharge of air and condensate.
- Temperature Regulators: The OB-30/OB-30U models, self/direct-acting temperature control valves for heating (steam to produce hot water), with a temperature range of 0-150°C, maximum pressure 1.0 MPa (1.7 MPa for hot water), maximum temperature 185°C, bronze body, and stainless steel valve seat materials.Temperature Regulators: The OB-30/OB-30U models, self/direct-acting temperature control valves for heating (steam to produce hot water), with a temperature range of 0-150°C, maximum pressure 1.0 MPa (1.7 MPa for hot water), maximum temperature 185°C, bronze body, and stainless steel valve seat materials.
- Control Valves: The CT-1 model, a single-seated globe control valve for steam, water, oil, air, and non-dangerous fluids, with 1.0 MPa pressure, JIS/EN/ASME flange connections, and a cast carbon steel body material.Control Valves: The CT-1 model, a single-seated globe control valve for steam, water, oil, air, and non-dangerous fluids, with 1.0 MPa pressure, JIS/EN/ASME flange connections, and a cast carbon steel body material.
- Other Valve and Fluid Control Products: Manual valves, safety and relief valves, strainers, assist traps/pumping traps, sight glass/flow sight, hot water navigators, emergency shutoff systems, primary pressure regulating valves, solenoid valves/motor valves, air vent valves/air vent valves with vacuum breaker, noiseless heaters/vacuum relief valves, expansion joints/ball joints/flexible joints, radiator traps/radiator valves, and flow meters, a diverse product portfolio.Other Valve and Fluid Control Products: Manual valves, safety and relief valves, strainers, assist traps/pumping traps, sight glass/flow sight, hot water navigators, emergency shutoff systems, primary pressure regulating valves, solenoid valves/motor valves, air vent valves/air vent valves with vacuum breaker, noiseless heaters/vacuum relief valves, expansion joints/ball joints/flexible joints, radiator traps/radiator valves, and flow meters, a diverse product portfolio.
- Core Advantages
- Self-Actuated Control Valve Technology: A valve design mechanically actuated by spring force without external energy, ensuring energy-saving and eco-friendly products.Self-Actuated Control Valve Technology: A valve design mechanically actuated by spring force without external energy, ensuring energy-saving and eco-friendly products.
- Comprehensive Fluid Control Solutions: Beyond valve manufacturing and sales, offering extensive solutions such as piping design consultation, energy-saving surveys, and production facility optimization tailored to customer needs.Comprehensive Fluid Control Solutions: Beyond valve manufacturing and sales, offering extensive solutions such as piping design consultation, energy-saving surveys, and production facility optimization tailored to customer needs.
- Over 80 Years of History and Technical Reliability: More than 80 years of accumulated technical reliability and a reputation for long product lifespan, holding the second-largest share in the domestic pressure-reducing valve market.Over 80 Years of History and Technical Reliability: More than 80 years of accumulated technical reliability and a reputation for long product lifespan, holding the second-largest share in the domestic pressure-reducing valve market.
- Vertically Integrated Production System and Strict Quality Control: An integrated production system controlling all processes from casting to machining, assembly, and shipment internally, along with rigorous QC/QA activities including precise analysis with latest facilities and risk assessment for minimal product defects.Vertically Integrated Production System and Strict Quality Control: An integrated production system controlling all processes from casting to machining, assembly, and shipment internally, along with rigorous QC/QA activities including precise analysis with latest facilities and risk assessment for minimal product defects.
- Global Network and International Standards Compliance: A global supply system with distribution channels in over 45 countries and 83 authorized distributors worldwide, providing internationally certified products compliant with Japanese, American, and European quality standards.Global Network and International Standards Compliance: A global supply system with distribution channels in over 45 countries and 83 authorized distributors worldwide, providing internationally certified products compliant with Japanese, American, and European quality standards.
- Continuous R&D and Product Improvement: Tireless research and development efforts and experimental verification over the years, delivering top quality and performance, with a commitment to improving products to adapt to changing market environments.Continuous R&D and Product Improvement: Tireless research and development efforts and experimental verification over the years, delivering top quality and performance, with a commitment to improving products to adapt to changing market environments.
- Target Industrie
- Machinery industryMachinery industry
- Plant facilities and piping systemsPlant facilities and piping systems
- Construction and building facilitiesConstruction and building facilities
- Public facilitiesPublic facilities
- Food processing and beverage productionFood processing and beverage production
- Pharmaceutical industryPharmaceutical industry
- Air conditioning systemsAir conditioning systems
- Water and sewage treatmentWater and sewage treatment
- Power generation plantsPower generation plants
- Semiconductor manufacturingSemiconductor manufacturing
- Boilers and fuel cell generatorsBoilers and fuel cell generators
- Hospitals and hotelsHospitals and hotels
- Major Markets
- Japan, Thailand, China, Malaysia, Indonesia, Singapore, Vietnam, Philippines, India, Hong KongJapan, Thailand, China, Malaysia, Indonesia, Singapore, Vietnam, Philippines, India, Hong Kong
- United StatesUnited States
- EcuadorEcuador
- Certifications/Patents
- Capability in obtaining internationally accredited quality assurance certifications, adhering to Japanese, American, and European quality standards.Capability in obtaining internationally accredited quality assurance certifications, adhering to Japanese, American, and European quality standards.
- Efforts in reducing environmental impact through the integration of eco-friendly designs in product development.Efforts in reducing environmental impact through the integration of eco-friendly designs in product development.
- Contribution to global environmental conservation and stable power supply through the introduction of a mega solar power system at the Thailand factory.Contribution to global environmental conservation and stable power supply through the introduction of a mega solar power system at the Thailand factory.
- Quality control throughout the entire production process, from casting to machining, assembly, and shipment, managed internally.Quality control throughout the entire production process, from casting to machining, assembly, and shipment, managed internally.
- Quality management activities minimizing product defects through precise analysis with advanced facilities and preventive measures like risk assessment.Quality management activities minimizing product defects through precise analysis with advanced facilities and preventive measures like risk assessment.
Introduction
Location
2-chōme-27-1 Gokisotōri, Showa Ward, Nagoya, Aichi 466-0015, Japan
