[ KU Band ]

High technology, Antenna for Maritime.


Wiworld‘s maritime Ku band communication system has various products with different parabola sizes ranging from 60cm to 1.2m. It is mainly installed on merchant vessels, cruise ships and battleships. With its quick data speed, easy installation and operation, it has been designed to be convenient to use. Wiworld can independently design antennas and instruments with original technology. Wiworld can develop and produce a customized antenna in reference to the needs of the clients.





Features

locking
Precise signal locking

Install

Easy installation and maintenance

High-performance

High data speed avaliable

System

Strong and stabilized gyro system




Detailed specifications

Above Deck
Dish Diameter60cm (23.6”)
Antenna Dimension71cm x 71cm x 74cm(H)
BUC4W / 6W, 8W
Operating Platform3-Axis
RX /TX Frequency BandTX : 13.75 ~ 14.5GHz Ku Band
RX : 10.70~12.7GHz Ku Band
HumidtyUp to 100% @ 40˚C
RX /TX Gain36dBi / 36.6dBi
LNBLinear / Internal PLL
Skew ControlAutomatic (-110˚ ~ +110˚)
Elevation Angle-10˚ ~ +100˚
Azimuth Range640˚
Cross Angle+/- 28˚
Tracking SpeedMore than 90˚/sec
Antenna Weight39kg
Radome MaterialPlastic / FRP *(Option)
Vibration DamperAntenna Fix bracket
Temperature-20˚C to 70˚C
Packing
Size78cm X 78cm X 89cm
Gross Weight55kg
Packed byPaper carton



Above Deck
Dish Diameter70cm (27.5")
Antenna Dimension95cm x 95cm x 95cm(H)
BUC4W / 6W, 8W
Operating Platform3-Axis
RX /TX Frequency BandTX : 13.75 ~ 14.5GHz Ku Band
RX : 10.70~12.7GHz Ku Band
HumidtyUp to 100% @ 40˚C
RX /TX Gain37.2dBi / 38dBi
LNBLinear / Internal PLL
Skew ControlAutomatic (-110˚ ~ +110˚)
Elevation Angle-10˚ ~ +100˚
Azimuth Range640˚
Cross Angle+/- 28˚
Tracking SpeedMore than 90˚/sec
Antenna Weight65kg
Radome MaterialFRP
Vibration DamperAntenna Fix bracket
Temperature-20˚C to 70˚C
Packing
Size128cm X 128cm X 140cm
Gross Weight95kg
Packed byWooden Crate


Above Deck
Dish Diameter90cm (35.4”)
Antenna Dimension114cm x 114 x 121cm(H)
BUC4W / 6W, 8W, 16W, 25W(Option)
Operating Platform3-Axis
RX /TX Frequency BandTX : 13.75 ~ 14.5GHz Ku Band
RX : 10.70~12.7GHz Ku Band
HumidtyUp to 100% @ 40˚C
RX /TX Gain39dBi / 39.8dBi
LNBLinear / Internal PLL
Skew ControlAutomatic (-110˚ ~ +110˚)
Elevation Angle-10˚ ~ +100˚
Azimuth RangeUnlimited
Cross Angle+/- 32˚
Tracking SpeedMore than 90˚/sec
Antenna Weight140kg
Radome MaterialFRP
Vibration DamperWire Rope Isolator
Temperature-20˚C to 70˚C
Packing
Size158cm X 158cm X 174cm
Gross Weight200kg
Packed byWooden Crate


Above Deck
Dish Diameter110cm (43.3”)
Antenna Dimension142cm x 142cm x 145cm(H)
BUC4W / 6W, 8W, 16W, 25W(Option)
Operating Platform3-Axis
RX /TX Frequency BandTX : 13.75 ~ 14.5GHz Ku Band
RX : 10.70~12.7GHz Ku Band
HumidtyUp to 100% @ 40˚C
RX /TX Gain40.3dBi / 41.4dBi
LNBLinear / Internal PLL
Skew ControlAutomatic (-130˚ ~ +130˚)
Elevation Angle-20˚ ~ +100˚
Azimuth RangeUnlimited
Cross Angle+/- 32˚
Tracking SpeedMore than 90˚/sec
Antenna Weight190kg (Include 8watt BUC)
Radome MaterialFRP
Vibration DamperWire Rope Isolator
Temperature-20˚C to 70˚C
Packing
Size174cm X 174cm X185cm
Gross Weight260kg
Packed byWooden Crate


Above Deck
Dish Diameter125cm (49.2”)
Antenna Dimension163cm x 163cm x 175cm(H)
BUC4W / 6W, 8W, 16W, 25W(Option)
Operating Platform3-Axis
RX /TX Frequency BandTX : 13.75 ~ 14.5GHz Ku Band
RX : 10.70~12.7GHz Ku Band
HumidtyUp to 100% @ 40˚C
RX /TX Gain41.3dBi / 42dBi
LNBLinear / Internal PLL
Skew ControlAutomatic (-130˚ ~ +130˚)
Elevation Angle-20˚ ~ +110˚
Azimuth RangeUnlimited
Cross Angle+/- 32˚
Tracking SpeedMore than 90˚/sec
Antenna Weight200kg(Include 8watt BUC)
Radome MaterialFRP
Vibration DamperWire Rope Isolator
Temperature-20˚C to 70˚C
Packing
Size180cm X180cmX 200cm
Gross Weight280kg
Packed byWooden Crate
