[ SM300P ]
High technology, In-motion Satellite Antenna for Maritime.
Wiworld‘s SM300P antenna is an in-motion and double-axis maritime antenna with a size of 45cm. Using this representative product of Wiworld, you can watch satellite broadcastings comfortably and constantly in a moving object, such as fishing boat, ship or yacht. Using the excellent S/W of Wiworld‘s exclusive tracking algorithm, you can watch high quality satellite broadcastings with few defects and an outstanding performance.
Features
- Excellent algorithm
- Supports satellite services all over the world
- The best quality due to double-axis stepping motor control
- Customized auto skew, multi output, GPS function
- Supports HD and SD
- One year free A/S provided

Enjoy Satellite TV in Maritime Vessel
Using the SM300P antenna with an outstanding algorithm, tracking performance and the Wiworld RF technology, you can enjoy satellite TV on a marine vessel or fishing boat.
Specification
Dimension Parabola size of 45cm and compact antenna with a radome size of 580*550(H)mm  | High-performance Algorithm Provides the best performance with an excellent algorithm and double-axis stepping motor control function Can receive various channels using a single antenna  | One year Warranty Provides free After-Sale Service for one year all around the world  |
Detailed Specifications
| Antenna Type | Parabola |
|---|---|
| Dish | 45 cm |
| Radome Dimension | 560*600 |
| Antenna Gain | 33 dBi |
| Min EIRP | 49 dBW |
| Polarization | Linear (V/H) |
| Skew Control | Manual / Automatic |
| Stabilized Type | 2-Axis Step motor |
| EL Range | 0 ~ 90 |
| AZ Range | Unlimit / 450 |
| GPS | Optional |
| Power | 12V, 3A |
| Multi-output | Optional |
Mounted photo
